107
Matchcode

FN045-ZIQ.DC.A5P4


Item number

ZV-184938

Product groupAxial fan
ModelStandard
Design
NameEcblue
Blade seriesFN
Fan series match codeFN045-ZI_.DC.A5P4
Blade diameter [cm]45
Motor technologyEC
Rated voltage UN [V] UN [V]1~200-277
Rated frequency fN [Hz]50/60
Input power P1 [kW]0,76
Rated current IN [A]3,9-3,3
Rated speed nN [min-1]1650
Current rating increase Δ I [%]
Controlling starting current IA [A]
Operating capacitor C400V [µF]
Thermal classTHCL 155
Minimum permissible flow medium temperature [°C]
Maximum permissible flow medium temperature [°C]60
Electrical connection
Sound pressure level LpA or LwA [dB(A)]
Number of wings5
Rotor
Wall ring platePlastic
Con­for­mity
Weight [kg]
Airflow directionA
ModelWall ring plate
Max. volume flow qv, (where psf = 0 Pa) [m³/h]7700
Max. pressure psf [Pa]187
Max. volume flow qv [m³/h] (at max. psf [Pa])5400
