MatchcodeFC040-4EQ.4C.A7Item number ZV-141036 |  |
|---|---|
| Product group | Axial fan |
| Model | ß - Agriculture |
| Design | |
| Name | |
| Blade series | FC |
| Fan series match code | FC040-4E_.4C.A7 |
| Blade diameter [cm] | 40 |
| Motor technology | AC |
| Rated voltage UN [V] UN [V] | 1~230 +/-10% |
| Rated frequency fN [Hz] | 50 |
| Input power P1 [kW] | 0,27 |
| Rated current IN [A] | 1,3 |
| Rated speed nN [min-1] | 1400 |
| Current rating increase Δ I [%] | |
| Controlling starting current IA [A] | 3,9 |
| Operating capacitor C400V [µF] | 6 |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | -25 |
| Maximum permissible flow medium temperature [°C] | 40 |
| Electrical connection | Junction box |
| Sound pressure level LpA or LwA [dB(A)] | |
| Number of wings | 7 |
| Rotor | Aluminium, 1-coat lacquer, jet black |
| Wall ring plate | |
| Conformity | ErP 2015, CE |
| Weight [kg] | 7 |
| Airflow direction | A |
| Model | D |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | 5200 |
| Max. pressure psf [Pa] | 75 |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) | 3600 |
 | |
