MatchcodeFC050-4EQ.4F.A7Item number ZV-130752 |  |
|---|---|
| Product group | Axial fan |
| Model | Standard |
| Design | Wire support grid/sheet metal |
| Name | |
| Blade series | FC |
| Fan series match code | FC050-4E_.4F.A7 |
| Blade diameter [cm] | 50 |
| Motor technology | AC |
| Rated voltage UN [V] UN [V] | 1~230V +/-10% |
| Rated frequency fN [Hz] | 50/60 |
| Input power P1 [kW] | 0,51 |
| Rated current IN [A] | 2,3/2,9 |
| Rated speed nN [min-1] | 1290/1230 |
| Current rating increase Δ I [%] | 5/0 |
| Controlling starting current IA [A] | |
| Operating capacitor C400V [µF] | 8 |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | -25 |
| Maximum permissible flow medium temperature [°C] | 70 |
| Electrical connection | Junction box |
| Sound pressure level LpA or LwA [dB(A)] | 78 |
| Number of wings | 7 |
| Rotor | Aluminium, 1-coat lacquer, black |
| Wall ring plate | Sheet of metal |
| Conformity | ErP 2015 |
| Weight [kg] | 16,6 |
| Airflow direction | A |
| Model | Q |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | 7600 |
| Max. pressure psf [Pa] | 120 |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) | 4500 |
 | |
