MatchcodeFC063-4DQ.6N.V7Item number ZV-155234 |  |
|---|---|
| Product group | Axial fan |
| Model | Standard |
| Design | UL |
| Name | |
| Blade series | FC |
| Fan series match code | FC063-4D_.6N.V7 |
| Blade diameter [cm] | 63 |
| Motor technology | AC |
| Rated voltage UN [V] UN [V] | 3~230/400 +/-10% / 3~265/460 +/-10% |
| Rated frequency fN [Hz] | 50/60 |
| Input power P1 [kW] | 2,1 |
| Rated current IN [A] | 6,6/3,8 / 8,7/5,1 / 8,6/5,0 |
| Rated speed nN [min-1] | 1320/1410/1500 |
| Current rating increase Δ I [%] | 5 |
| Controlling starting current IA [A] | |
| Operating capacitor C400V [µF] | |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | -40 |
| Maximum permissible flow medium temperature [°C] | 70 |
| Electrical connection | Junction box |
| Sound pressure level LpA or LwA [dB(A)] | 89-70 |
| Number of wings | 7 |
| Rotor | Aluminium, 1-coat lacquer, black |
| Wall ring plate | Sheet of metal |
| Conformity | ErP 2015 |
| Weight [kg] | 39,6 |
| Airflow direction | V |
| Model | Q |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | 22000 |
| Max. pressure psf [Pa] | 340 |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) | 12000 |
 | |
