MatchcodeFN071-ZIQ.GG.A7P4Item number ZV-180838 |  |
|---|---|
| Product group | Axial fan |
| Model | Standard |
| Design | Suitable for textile ventilation hoses / ducts |
| Name | ECblue |
| Blade series | FN |
| Fan series match code | FN071-ZI_.GG.A7P4 |
| Blade diameter [cm] | 71 |
| Motor technology | EC |
| Rated voltage UN [V] UN [V] | 3~380-480V |
| Rated frequency fN [Hz] | 50/60 |
| Input power P1 [kW] | 1,95 |
| Rated current IN [A] | 3,2-2,5 |
| Rated speed nN [min-1] | 1150 |
| Current rating increase Δ I [%] | |
| Controlling starting current IA [A] | |
| Operating capacitor C400V [µF] | |
| Thermal class | THCL 155 |
| Minimum permissible flow medium temperature [°C] | -35 |
| Maximum permissible flow medium temperature [°C] | 65 |
| Electrical connection | Integrated controller |
| Sound pressure level LpA or LwA [dB(A)] | 55-87 |
| Number of wings | 7 |
| Rotor | Aluminium, 1-coat lacquer, ultramarine blue |
| Wall ring plate | Wall ring, steel, powder-coated, deep black |
| Conformity | ErP 2015 |
| Weight [kg] | 36,8 |
| Airflow direction | A |
| Model | Q |
| Max. volume flow qv, (where psf = 0 Pa) [m³/h] | 20000 |
| Max. pressure psf [Pa] | 230 |
| Max. volume flow qv [m³/h] (at max. psf [Pa]) | 11500 |
 | |
