1050

Temperature control unit

ZR-303617

ApplicationPTE control systems / regulator
Match codePTE-10AHQ-L
FeaturesIB=10,0 A
Functional descriptionEquipment/characteristics:
• Main switch with bypass function
• Operation via direct selection keys and LC multifunction display with clear text display
• Sensor input 1 for section (in delivery: 1 x TFR model, item no. 00089846)
• Sensor input 2 for: inlet air temperature, separate control circuit or O-10 signal from humidity/temperature sensor (model MFTG-100V, item no. 384033).
• Three 0 - 10 V outlets, alternatively 10 - 0 V e.g. for flaps, heater, group 2, separate control circuit, PWM outlet can alternatively be used as another 0 - 10 V outlet
• Three relay outlets, e.g. for: Fault, heater. Flap. Peak load. Group switching
• Networking of max. 32 devices via RS485 interface (Modbus) for inlet air temperature, alarm signals and central functions.
• Growth curves with start value, 2 inflexion points and an end value, for target value, minimum ventilation, maximum ventilation, heater1, heater2.
• Automatic closing mechanism by adjusting the target value when the control range is exceeded
• Function for regulating heat exchanger and inlet air flap
• Integrated control for piglet nest warm water heater (heater2)
• Special modes for washing and heating
• Integrated semiconductor fuse
• Alarm buffer for the last 10 reports
• Minimum and maximum temperature value storage
• Optional. Integration into remote maintenance system
Technical data1~230V, 50/60Hz, IP 54, 2,5 kg
Size (R = for pipe installation) / dimensions
Series
Motor size
