Temperature control unitMatch codeCTG-150AVItem number ZR-320073 |  |
|---|---|
| Application | UNIcon CTG-150AV Temperature control module |
| Features | 10...24 V DC (+20 %) Supply from fan |
| Functional principle | Temperature control via 0-10V output to a speed controller for fans, for example |
| Functional description | The actual value measured at the sensor is compared with the set target value. The output voltage and thus the speed of the fan is automatically changed depending on the set parameters. When using the device for animal husbandry, do not install it directly in the barn if possible, but in an anteroom with reduced pollution. Alternatively, the device can be operated as a temperature sensor. The 0 - 10 V output is then proportional to the adjustable measuring range (max. -50...150 °C). |
| Technical data | Ausgangssignal 0-10V, Spannungssversorgung aus Ventilatormotor 10-24V, -10-+60°C |
| Size (R = for pipe installation) / dimensions | |
| Series | for EC fans with 0-10V input signal |
| Motor size | |
 | |
