Frequency converterMatch codeFSDM17AItem number ZR-308415 |  |
|---|---|
| Application | 8~I-control FSDM PMIcontrol Basic for IEC standard motors |
| Features | IB = 17 A |
| Functional principle | Frequency inverter for speed control of 3 ~ motors and PM motors. Optional function as a frequency inverter for a 3 ~ asynchronous motor or as a frequency inverter for a permanent magnet synchronous motor, PM motor. Frequency inverters from the PMIcontrol series are designed for the speed control of a single three-phase asynchronous motor or a permanent magnet synchronous motor. Only suitable for drives with low breakaway torque, e.g. for fans or pumps. The motor's insulation system and ball bearings must be suitable for operation on the frequency inverter. suitable for operation on the frequency inverter. For the operation of ZIEHL-ABEGG external rotor motors on frequency inverters, all-pole effective sine filters are required. sine filters are required. This is integrated in ZIEHL-ABEGG frequency inverters of the Fcontrol series. This means that parallel operation of several motors is also possible without any problems. |
| Functional description | After the mains voltage is applied, the device recognises whether there is a ZAstick in the parameter interface. - AC motor operating mode - When delivered without a ZAstick, the device operates as a frequency inverter for an asynchronous motor. A 3 ~ output with variable voltage and frequency is generated from the three-phase mains at the input. - PMotor operating mode - If a parameter set for a PM motor is recognised, the device operates as a frequency inverter for a permanent magnet synchronous motor. The ZAstick with parameter set is supplied with the PMotor. -Flat menu structure, no submenus -Display with plain text display, no code lists necessary -The two previous points result in quick and easy commissioning -easy parameterisation also possible via an APP with a smartphone (prerequisite: installed AM-STICK-WB) -MODBUS RTU bus interface already integrated, with the option of automatic addressing for multiple devices on one bus line Translated with DeepL.com (free version) |
| Technical data | Netzspannung 3~208…480V, 50/60Hz, Bemessungsspannung 400V, geregelte Ausgangsspannung ~0…100%, empfohlene Motorleistung 7,5kW, IP55, Bemessungstemperatur 55°C, 7,8kg |
| Size (R = for pipe installation) / dimensions | |
| Series | for IEC standard motors |
| Motor size | |
 | |
